Near ubiquitous broadband Internet connecting a multitude of distributed embedded systems in the IoT world, introduces new challenges in data transfer performance and communication security.
The Oxalis meets these challenges head on and provides a high performance IoT gateway solution with low power consumption in a modular architecture.
Additional Information
| Component | Description |
|---|---|
| SoC | NXP Layerscape LS1012A |
| CPU | Cortex-A53 |
| RAM | 1GByte |
| PMU | NXP VR5100 |
| Storage | 64MByte SPI Flash for bootloader and RCW + MicroSD Card slot + SATA |
| Ethernet Port | 2x 10/100/1000 |
| USB | 2x USB 3.0 |
| Expansion Interface | 40 pin low speed expansion connector: +1.8V, +5V, SYS_DCIN, GND, UART, I2C, SPI, PCM, PWM,GPIO x12 |
| Button | Reset |
| Power Source | 12V@2.5A, 2.5mm center pin 8A DC jack connector, CUI Inc PJ-063BH or equivalent |
| OS Support | Debian GNU Linux |
| Size | 160x120mm |
